5.0

TrailMaster 200 XRS Go Kart

Retail Price:$3,799.95
$3,099.00
(You save $700.95)
SKU:
TM-200XRS
Checking availability...

Color: *

Backup Color Choice: *

Assembly Option: *

Shipping Consent*

Notarized MSO:

Overview

Product Description

If you're looking for a go-kart that can do just about anything then you should check out the TrailMaster 200 XRS. This model is certainly a great way to enjoy some leisure time, but with a weight limit of 500 pounds and a built on hitch and storage basket, you'll be able to do so much more with this vehicle.

The 200 XRS is made with speed in mind and can take you up to 35 MPH, which is much faster than many other models. This speed increase is largely due to the fantastic single cylinder engine and CVT clutch that allows for ten horse power. Of course, the optimized frame of this model also allows for a reduced turning radius so you can have a little extra fun while working or creaming your friends in a race.

The design of the 200 XRS features cozy bucket seats that will adjust to help the driver maintain a comfortable driving position. Each seat contains a seat belt, which is only one of the amazing safety features this model has. The 150 XRS also boasts durable headlights, tail lights and hydraulic brakes ( front and rear) that will ensure the driver has complete control day or night. Your model will also include a 2.25 gallon fuel tank, electric starting system and dual wheel drive that will ensure your go-kart time won't just be a whole lot of fun, but will improve your skills while you spend hours out in the fields.

EPA certificated
Engine type: 4-stroke, single cylinder, air cooled
Displacement: 150cc
Max HP: 8.2hp/7500rpm
Max torque: 7 lb ft/6000rpm
Bore x stroke: 2.26 x 2.28 inches
Max speed: 43.5mph
Climbing ability: 12 degrees
Ignition: C.D.I
Starting system: Electric
Battery: 12V 10Ah
Carburetor brand: Deli (Vacuum film)
Engine oil: SAE 15W-40
General Information
Clutch: Automatic CTV with reverse
Driveline / Driving wheel: Chain / Dual wheel drive
Suspension, F / R: Double A-arm / swing-arm
Brakes, F / R: Both hydraulic brakes, Disc
Tires, F / R: 20x7-8 / 22x10-10
Fuel capacity: 2.25 gal
Weight, G.W. / N.W.: 573 / 485 lbs
Max load: 500 lbs
Dimension Information
Wheelbase: 61 inches
OA L x W x H: 85x53.1x57.5 inches
Height to seat: 13.8 inches
Min ground clearance: 6.7 inches

Things To Know:

  • Thank you for considering GoPowerSports as your source for quality outdoor power sports needs. We take pride in our commitment to providing excellent customer service and support. We aim to ensure complete satisfaction with your purchase and encourage you to review our warranty policies carefully. If you have any questions, please feel free to contact us via email at sales@gopowersports.com or by calling 1-866-846-5278.
  • We highly recommend that you have a professional mechanic or an authorized dealer of the manufacturer perform the initial assembly and preparation of the vehicle.
  • We want you to know that basic repair and setup skills are necessary for buyers, such as using tools, replacing nuts and bolts, filters, light bulbs, fluids, and making adjustments. If you lack these skills, we suggest seeking the assistance of a mechanic. Our tech support hotline is always available to help you.
  • These vehicles ship with break-in oil.  Must check oil levels before initial start up and fill with quality oil if low.
  • Check over all Nuts and Bolts to ensure they are fastened before and after initial ride.
  • This vehicle is meant for recreational use only.

Warranty:

  • 90 Day Limited Warranty on Frame & Engine; 30 Day Limited Warranty on Non-Wear Items.
  • The limited warranty covers specific parts only, including the engine, engine case, drive system, fuel system, electrical system, cooling system, brakes, chassis, and transmission. Please note that the warranty does not cover any damage caused by improper use, such as jumping, stunt riding, modification, racing, or riding at constant wide-open throttle.
  • Please be aware that the following parts are NOT covered by the warranty: tires, rims, body panels, forks, shocks, gaskets, light bulbs, seats, CV boots, oil filters, air filters, fuel filters, clutch wear parts, cables, drive belts, chains, spark plugs, rubber parts, belts, brake linings and/or pads, batteries, sprockets, external springs, clips, nuts, bolts, and fasteners.
  • Our warranty does not cover damages caused by improper assembly, maintenance, or usage that falls outside of the manufacturer's specifications.
  • Also, please note that no returns are accepted on this unit.

Shipping:

  • If you purchase a TrailMaster Unit, please know that it only ships to the lower 48 states.  Contact us if you would like a quote for shipping to Hawaii or Alaska.
  • If unit is shipped to California, then it can only be used on Private Land if the engine is not EPA or CARB compliant.
  • Please allow 3-5 business days for your unit to ship. Once shipped, a tracking number will be emailed to you. The shipping company will contact you to confirm delivery.
  • If choosing Unassembled in Crate, you will be responsible for handling the crate whether it is delivered residential, local Carrier Terminal, or business dock.  This may require a forklift.
  • If choosing Mostly Assembled in Crate, you will be responsible for handling the crate whether it is delivered residential, local carrier terminal, or business dock.  This may require a forklift.
  • If choosing Fully Assembled, Residential Delivery is available by car hauler or flat bed.

Assembly:

  • You may choose to receive this vehicle unassembled in the crate and take advantage of Free Shipping within the lower 48 States.  You would be responsible to complete assembly.
  • You may choose to receive this vehicle partially assembled in crate.  You will need to attach the roll cage, battery, steering wheel, and a few other adjustments.
  • The other option is to have this unit 100% built at the warehouse and then transported to you by a car hauler or flat bed.

Manufacturer Statement of Origin:

  • You may request a notarized Manufacturer Statement of Origin.  This may be used for insurance, titling, etc.  These MSOs will be shipped separately to your shipping address.



Product Specification

Weight
400lb
GTIN
662652724668
UPC
662652724668
