Lil' Rascal 212 Mini Bike Kit

Lil' Rascal 212 Mini Bike Kit with Tillotson 212E Pull-Start Engine

LIMITED-TIME OFFER: Upgrade to a gloss-black powder-coated Lil' Rascal frame set at no additional charge while supplies last. Select your preferred frame finish before adding the kit to your cart.

ENGINE INCLUDED: This kit includes the Tillotson 212E Hemi Racing Engine with Pull Start.

Build a compact, vintage-style mini bike with serious small-block power. The Lil' Rascal 212 Mini Bike Kit combines our American-made Lil' Rascal frame with a Tillotson 212E engine, Stage 1 performance components, 6-inch wheels, hydraulic braking, a complete #420 drivetrain and the essential controls, fuel-system components and mounting hardware needed to complete the build.

The Lil' Rascal captures the appearance of a classic old-school mini bike in a compact package. Its low seat height works well for smaller riders, while its tall handlebars and carefully selected frame dimensions can accommodate many adult riders. Review the listed dimensions to determine whether the Lil' Rascal is appropriate for your intended rider.

This is an unassembled mini bike kit. Assembly, adjustment and a complete safety inspection are required before operation.

Choose Your Frame Finish

• Gloss Black Powder Coat: A durable, finished appearance offered as a free upgrade for a limited time while supplies last
• Bare Steel: Ready for your choice of paint, powder coat or custom finish

The selected finish applies to the Lil' Rascal frame and handlebar/fork assembly. Neck, axle and mounting hardware retain their standard finishes.

If you select bare steel, we recommend completing a full mock-up before applying paint or powder coat. Minor fitting, alignment or hole adjustments should be completed before the final finish is applied. Modifications made to a powder-coated frame may require finish touch-up.

Required Product Selections

• Frame Finish: Gloss Black Powder Coat or Bare Steel
• Seat: Select your preferred seat color
• Front and Rear Tires: Select your preferred tire option

Kit Features

• Compact, vintage-inspired mini bike design
• American-made Lil' Rascal steel frame
• Heavy-duty 7/8" OD frame tubing with a .120" wall
• Tillotson 212E Hemi Racing Engine with recoil pull start
• 9+ HP stock engine output
• Standard 3/4" keyed horizontal output shaft
• Stage 1 intake and exhaust components
• 6" Mega Moto mag wheels with 12mm bearings
• Hydraulic rear brake assembly
• Complete #420 chain drivetrain
• External black 8" aluminum fuel tank
• Seat and tire options selected by the customer

Dimensions & Specifications

• Seat Height: Approximately 18" to the bottom of the seat
• Handlebar Height: Approximately 31"
• Engine Mount to Bottom of Seat Frame: Approximately 10.5"
• Wheelbase: Approximately 31.75"
• Engine Mounting Pattern: Approximately 6.375" x 3.125"
• Main Frame Tubing: 7/8" OD steel tubing with a .120" wall
• Front and Rear Axles: 12mm
• Engine: Tillotson 212E Hemi Racing Engine
• Engine Starting System: Recoil pull start
• Engine Output Shaft: 3/4" keyed horizontal shaft
• Drive Chain: #420
• Included Clutch: 10-tooth, 3/4" bore, #420 chain

Parts Included

Frame, Steering & Controls

• Lil' Rascal Mini Bike Frame
• Lil' Rascal Handlebar and Fork Assembly
• Lil' Rascal Neck Bolt Kit, including neck bolt, nut and washers
• (2) 1/2" Flanged Neck Bushings
• M12 x 220mm Front Axle Bolt and Nut
• (2) 12mm Front Axle Spacers
• 7/8" Handlebar Engine Kill Switch
• Mega Moto Throttle Twist Grip and Housing
• Mega Moto Mini Bike Throttle Cable
• 7/8" Rubber Foot-Peg Grips, Pair

Wheels, Tires & Braking Components

• 6" Mega Moto Front Mag Wheel with (2) 6201 Bearings, 32mm OD x 12mm ID
• Front 6" tire selected using the required tire option
• Left-Hand Hydraulic Brake Assembly, including lever, hydraulic hose, caliper and brake pads
• Brake Caliper Mounting Bolts, Spacers and Lock-Washer Hardware
• 6" Mega Moto Rear Mag Wheel with (2) 6201 Bearings, 32mm OD x 12mm ID
• Rear 6" tire selected using the required tire option
• M12 x 260mm Rear Axle Bolt and Nut
• (2) 12mm Rear Axle Spacers
• Mini Bike Brake Disc, 6-Hole
• (12) Rear Wheel, Sprocket and Brake Disc Mounting Bolts

Drivetrain Components

• 54-Tooth #41/#420 Dual-Pattern Sprocket
• #420 Drive Chain, supplied in the required length
• 10-Tooth GPS Centrifugal Clutch, 3/4" Bore and #420 Chain
• Chain Tension Roller Assembly, including pulley, bearings, mounting bolt, washer and locking nut
• Mini Bike Kickstand Kit

Depending on parts availability, the rear sprocket may be supplied as a one-piece sprocket or as a separate GoPowerSports sprocket hub and 54-tooth sprocket.

Fuel-System Components

• 8" Black Aluminum Cylinder Fuel Tank
• Lil' Rascal Rear Fuel-Tank Mount
• (2) Fuel-Tank Bands
• (2) Fuel-Tank Bracket Mounting Bolts
• (2) Fuel-Tank Bracket Mounting Nuts
• Plastic 90-Degree Fuel Outlet Barb
• 1/4" ID Fuel Line

Seat, Body & Finishing Components

• 12" Lil' Rascal Mini Bike Seat in the selected color
• (3) Seat Mounting Screws
• Mini Bike Chain Guard with GoPowerSports Logo
• (3) Chain Guard Mounting Bolts
• Lil' Rascal Front Plate with Mounting Hardware
• Engine Mounting Hardware
• Lil' Rascal Front Plate Sticker
• Lil' Rascal Pull-Start Circle Sticker
• Lil' Rascal Script Sticker

Engine & Performance Components

• Tillotson 212E Hemi Racing Engine, Pull Start
• Stage 1 Performance Kit for 196cc/212cc Engines
• Skinny Center-Exit Header Pipe
• Vent Filter Kit

Additional Items Required

• Gasoline
• Engine oil—the Tillotson engine ships dry and must be filled with the correct oil before starting
• Basic assembly tools
• Thread-locking compound where appropriate
• Approved helmet and appropriate protective riding equipment

For initial engine operation and break-in, consider adding Tillotson Break-In Oil.

Assembly & Pre-Ride Inspection

This mini bike is shipped as an unassembled kit. The customer is responsible for proper assembly, engine installation, clutch and chain alignment, cable routing, brake adjustment, fastener torque and final inspection.

Use the appropriate lock washers with the brake-caliper spacer hardware. Before every ride, confirm that the throttle returns freely, the engine shuts off correctly, the brakes operate properly and all steering, wheel, axle and drivetrain hardware is secure.

Recheck all fasteners, chain tension, wheel hardware and brake components after the initial break-in period. Routine inspection and maintenance are required for safe operation.

Important Safety & Shipping Information

This product is intended for off-road recreational use on private property where permitted. It is not designed or approved for use on public roads. Always wear a properly fitted helmet and appropriate protective equipment. Young riders require responsible adult supervision.

Powersports activities involve inherent risks that may result in injury, property damage or death. The purchaser and operator are responsible for proper assembly, inspection, maintenance, safe operation and compliance with all applicable laws.

California restriction: Because this kit includes the Tillotson 212E racing engine, it is not for use in California and cannot be shipped to California addresses.

Adult signature required upon delivery.

Lil' Rascal frame proudly made in the USA.

Limited-time finish availability: The complimentary gloss-black powder-coated frame upgrade is available only while supplies last. Select the desired frame finish before adding the kit to your cart. If the gloss-black option is no longer displayed, it is no longer available.
